Name: 3+9 Pin M19 Industrial Plug Socket Plastic PA66 Waterproof Power And Data Connector
Brand: Shenzhen Ulinkcon Technology Co., Ltd.
SKU: M19
Availability: InStock

Home Products Multi Pin Connectors Waterproof

3+9 Pin M19 Industrial Plug Socket Plastic PA66 Waterproof Power And Data Connector

Product Details:

Place of Origin:	China
Brand Name:	Ulinkcon
Certification:	CE/Rohs
Model Number:	M19

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiation
Price:	Negotiation
Packaging Details:	Box
Delivery Time:	5~8 working days
Payment Terms:	T/T,D/A,D/P,MoneyGram,L/C
Supply Ability:	100000 pairs each month

Contact Now

Detailed Product Description

Number Of Pins:	3+9 PIN	Current:	15A
Waterproof Rating:	IP67	Temperature Range:	-40℃~+105℃
Material:	Nylon	Connecting Mode:	Push Locking
Highlight:	M19 industrial waterproof plug socket , PA66 waterproof power connector , 3+9 pin data connector waterproof

Quick Release Wire Connector M19 3+9 Pin OEM Waterproof 300V Connector

Quick Details of 5Pin waterproof connector

1. 3+9 Pin Dual-Function Isolated Design

Featuring a 3-pin power + 9-pin data composite pin configuration, this connector enables independent transmission of power and signals. The 3-pin power channel supports stable high-power output to meet the power supply requirements of industrial equipment, while the 9-pin data channel is optimized for high-speed, low-interference signal transmission, suitable for various industrial control data interaction scenarios. The compact M19 form factor integrates dual functions into one, eliminating the need for multiple sets of connectors, significantly saving installation space and simplifying complex industrial wiring processes.

2. PA66 Engineering Plastic Housing for Industrial-Grade Durability

The housing is precision-injection-molded from PA66 engineering plastic, offering excellent mechanical strength, wear resistance, and corrosion resistance, and can withstand a wide operating temperature range of -40℃~105℃. Compared with ordinary plastic materials, the PA66 housing performs better in impact resistance, UV resistance, and chemical medium resistance, and can adapt to the harsh working conditions of industrial sites for a long time, ensuring the structural stability and service life of the connector.

3. High-Grade Waterproof Protection for Full-Scenario Adaptation

With a precision-sealed structure and waterproof gasket design, the connector achieves an IP67 waterproof and dustproof rating, effectively resisting the impact of harsh environments such as rain immersion, dust accumulation, and moisture condensation. Whether in humid factory workshops, outdoor equipment base stations, or salt-fog-corrosive marine operation scenarios, it can maintain stable electrical connection performance, ensuring all-weather reliable operation of equipment.

4. Easy Plug-In Design for Improved Installation Efficiency

Equipped with a user-friendly quick plug-in locking mechanism, it supports tool-free, one-handed operation. Simply align and press the male and female connectors to complete a secure lock, effectively preventing disconnection caused by vibration, impact, or accidental pulling. Compared with traditional threaded connection methods, the installation efficiency is improved by more than 50%, making it more suitable for batch deployment and later maintenance scenarios.

Main Features

Push lock quick release system
Multic-core options: 2Pin,3Pin,4Pin,5Pin for Power
3+2Pin,3+3Pin,3+4Pin,3+5Pin,3+9Pin and 2+20Pin for power signal combined
6Pin,7Pin,8Pin,9Pin,10Pin,11Pin,12Pin,14Pin,16Pin and 18Pin for signal available
Field assembly version:both wire to wire and wire to board options
Current rated 20A for long time working
Cable assembly service supported, welcome to custom
OEM/ODM welcome

Product Type Features
Connector System	Cable-to-Board
Sealable	Yes
Connector & Contact Terminates To	Wire & Cable
Circular Connector Type	Plug, Receptacle
Shell Type	Plastic Shell
Product Type	Connector Kit

Electrical Characteristics
Number of Poles	3+9
Current Rating	15A max
Voltage Rating	600VAC max
Durability Voltage	2500VAC @ 60 s.

Body Features
Shell Material	PA66
Circular Connector Insulation Material Type	Low Fire Hazard Thermoplastic
Hermetically Sealed	Yes
Entry Style	Side
Environmental Protection Type	Elastomer Sealed, Hermetically Sealed
O-Ring Material	Elastomer Sealed, Hermetically Sealed
Environmental Protection	Yes

Usage Conditions
Operating Temperature Range (°C)	-40 ~105°C
IP Water Sealing Level	IP67
IP Dust Sealing Level	6
Operation/Application
Durability Rating (Cycles)	250, 251
Industry Standards
UL Flammability Rating	UL 94V-0

Application industries

Communications Application
product coding machines
inventory product coding
inkjet systems
Solar System
industrial inkjet equipment
Electric power equipment
Laboratory forensic&pathology equipment
Communications equipment
Heavy machinery

Production Dimension

More Technical Details

FAQ

Q1:What is rated voltage?

A1:Rated voltage also known as operating voltage, which mainly depend on the connector insulation material used, the spacing between the size of contact. Some of the components or devices in less than its rated voltage may not be completed to its functions.

Q2:How many materials you can provide?

A2: There's some different materials from connector and cable, we usually use PVC/Nylon material to product connector, PVC/Rubber/Silicone material was used in cable. Of course we can also according to your requirments to choose the material.

Q3:Do you accept other payment currencies besides USD?

A3: Our default currency is USD, but we can also accept EUR, GBP, or other major currencies. Please confirm the exchange rate with our sales team when placing the order.
