Name: 3+5 Pin M19 Male Female Cable Connectors 300V Waterproof Quick Disconnect Connectors
Brand: Shenzhen Ulinkcon Technology Co., Ltd.
SKU: M19
Availability: InStock

Home Products Multi Pin Connectors Waterproof

3+5 Pin M19 Male Female Cable Connectors 300V Waterproof Quick Disconnect Connectors

Product Details:

Place of Origin:	China
Brand Name:	Ulinkcon
Certification:	CE/Rohs/TUV/UL
Model Number:	M19

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiation
Price:	Negotiation
Packaging Details:	1.Plastic bag;2.Carton;3.As per customer's requirements
Delivery Time:	3~6working days
Payment Terms:	T/T,D/P,L/C,D/A,,Western Union,MoneyGram
Supply Ability:	100000 pairs Montly

Contact Now

Detailed Product Description

Current Rating:	15A	Rated Voltage:	300V
Pin:	3+5Pin	Connector Type:	Quick Connector
Material:	Nylon	Contact Material:	Brass Gold-Plated
Highlight:	3+5 pin waterproof cable connectors , M19 quick disconnect connectors , 300V waterproof male female connectors

15A Waterproof Data Cable Connector 3 +5 Pin M19 IP67 Circular Connectors

Quick Description

Product Overview: A professional-grade connectivity option designed for male-female paired cable connections, featuring 3+5 pin configuration, M19 standard size, and 300V rated voltage. Specialized in quick disconnect functionality, it realizes efficient assembly and disassembly while ensuring reliable power and signal transmission.
Core Specifications: 3 power pins + 5 data pins separated layout; rated voltage 300V,industrial low-voltage application scenarios; supports quick disconnect operation, no tools required for pairing/unpairing; IP67 waterproof and dustproof rating, suitable for harsh indoor/outdoor environments.
Key Advantages: Male-female precise pairing design avoids misinsertion; quick disconnect mechanism improves maintenance and replacement efficiency; high-quality insulating material ensures 300V voltage stability and safety; reinforced housing with sealing structure resists water splashes and dust intrusion.
Application Scenarios: Widely used in industrial control systems, outdoor lighting equipment, low-voltage power distribution devices, and electronic equipment requiring frequent disconnection, perfectly matching the demand for quick and stable connection in 300V low-voltage scenarios.

Electrical Parameters
Number of Poles	3+5Pin
Current Rating	15A max.
Voltage Rating	300VAC max
Durability Voltage	1500VAC @ 60 s.

Main Features

Push lock quick release system
Multic-core options: 2Pin,3Pin,4Pin,5Pin for Power
3+2Pin,3+3Pin,3+4Pin,3+5Pin,3+9Pin and 2+20Pin for power signal combined
6Pin,7Pin,8Pin,9Pin,10Pin,11Pin,12Pin,14Pin,16Pin and 18Pin for signal available
Field assembly version:both wire to wire and wire to board options
Current rated 20A for long time working
Cable assembly service supported, welcome to custom
OEM/ODM welcome

Technical Parameters
Contact Resistance	10 mΩ max
Insulation Structure	500 MΩ at 500VDC
Operating Temperature	-40°C ~ +105°C
IP Class	IP67 (1m / 30min) when mated
Mold Material	PA66
Contact/Terminal Material	Gold Plated Brass
Seal Material	Silicone

Operation Parameters
Voltage Rating	300VAC max
Current Rating	5A max
Min Wire Size OD	3.0mm ~ 6.0mm
Max Wire Size OD	8.0mm ~ 10.0mm
Max.Cable Cross Section Area	0.5mm² ~ 2.5mm²
