M19 Plastic Male Female Connectors 3+2 Pin Circular Power And Signal Connector

Product Details:

Place of Origin:	China
Brand Name:	Ulinkcon
Certification:	CE/Rohs
Model Number:	M19

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiation
Price:	Negotiation
Packaging Details:	Box
Delivery Time:	5~8 working days
Payment Terms:	T/T,D/A,D/P,MoneyGram,L/C
Supply Ability:	100000 pairs each month

Contact Now

Detailed Product Description

Number Of Pins:	3+2PIN	Waterproof Rating:	IP67
Temperature Range:	-40℃~+105℃	Color:	Black Blue White Red Yellow
Type:	Waterproof Connector	Housing Material:	PA66
Highlight:	M19 waterproof circular connector , 3+2 pin plastic connector , male female signal power connector

M19 Plastic Male Female Connectors 3+2 Pin Circular Power And Signal Connector

Product Overview

Multi Pin Male Female Connector M19 3+2 Pin Wire To Wire Low Current Power Data Connector

Core Positioning

A 2-in-1 power and data connector designed specifically for low-current scenarios, compatible with standard M19 specifications. Adopting a 3+2 composite pin layout, it realizes independent and simultaneous power supply and data transmission, and is an efficient and reliable connection solution for small smart devices in wire-to-wire connection scenarios.

Core Parameters

3+2 composite pin configuration, IP67 dustproof and waterproof rating, capable of resisting moisture and dust intrusion, suitable for complex outdoor and industrial auxiliary scenarios; standard M19 thread size to ensure installation compatibility and connection tightness.

Performance Advantages

Adopting a composite pin independent channel design, power and data transmission do not interfere with each other, ensuring the accuracy of data transmission; equipped with an automatic locking connection structure to enhance connection firmness and vibration resistance, avoiding accidental disconnection; high-quality weather-resistant engineering plastic housing + high-conductivity copper alloy contacts, anti-oxidation and corrosion-resistant, extending product service life.

Installation & Compatibility

Male-female quick docking design, smooth and convenient plugging and unplugging, no professional tools required for installation and disassembly; standard M19 size is compatible with most small industrial equipment and smart terminal interfaces, and the wire-to-wire direct connection method simplifies the wiring process and reduces construction and later maintenance costs.

Main Features

Push lock quick release system
Multic-core options: 2Pin,3Pin,4Pin,5Pin for Power
3+2Pin,3+3Pin,3+4Pin,3+5Pin,3+9Pin and 2+20Pin for power signal combined
6Pin,7Pin,8Pin,9Pin,10Pin,11Pin,12Pin,14Pin,16Pin and 18Pin for signal available
Field assembly version: both wire to wire and wire to board options
Current rated 20A for long time working
Cable assembly service supported, welcome to custom
OEM/ODM welcome

Technical Specifications

Product Type Features	Connector System: Cable-to-Board Sealable: Yes Connector & Contact Terminates To: Wire & Cable Circular Connector Type: Plug, Receptacle Shell Type: Plastic Shell Product Type: Connector Kit
Electrical Characteristics	Number of Poles: 3+2 Current Rating: 15A max Voltage Rating: 600VAC max Durability Voltage: 2500VAC @ 60 s.
Body Features	Shell Material: PA66 Circular Connector Insulation Material Type: Low Fire Hazard Thermoplastic Hermetically Sealed: Yes Entry Style: Side Environmental Protection Type: Elastomer Sealed, Hermetically Sealed O-Ring Material: Elastomer Sealed, Hermetically Sealed Environmental Protection: Yes
Usage Conditions	Operating Temperature Range: -40°C to 105°C IP Water Sealing Level: IP67 IP Dust Sealing Level: 6
Operation/Application	Durability Rating: 250, 251 cycles
Industry Standards	UL Flammability Rating: UL 94V-0
