Name: 3+13 Pin M25 Multi Pin Male Female Connector PA66 Waterproof 300V Push Lock Connector
Brand: Shenzhen Ulinkcon Technology Co., Ltd.
SKU: M25
Availability: InStock

Home Products Waterproof LED Connector

3+13 Pin M25 Multi Pin Male Female Connector PA66 Waterproof 300V Push Lock Connector

Product Details:

Place of Origin:	China
Brand Name:	Ulinkcon
Certification:	CE/Rohs/TUV/UL
Model Number:	M25

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiation
Price:	Negotiation
Packaging Details:	Box
Delivery Time:	5~8 working days
Payment Terms:	T/T,D/A,D/P,,L/C
Supply Ability:	100000 pairs each month

Contact Now

Detailed Product Description

Number Of Pins:	3+13PIN	Current:	15A+5A
Flame-resistant Rating:	UL94-V0	Temperature Range:	-40℃~+105℃
Housing Material:	PA66	Contact Material:	Brass Gold-Plated
Highlight:	M25 waterproof push lock connector , PA66 multi pin male female connector , 300V waterproof LED connector

3+13 Pin M25 Multi Pin Male Female Connector PA66 Waterproof 300V Push Lock Connector

Main Features

Push lock quick release system
Multic-core options: 2Pin,3Pin,4Pin,5Pin,3+2Pin,3+3Pin,3+9Pin,3+13Pin and 2+20Pin
Field assembly version:both wire to wire and wire to board options
Current rated 20A for long time working
Cable assembly service supported, welcome to custom
OEM/ODM welcome

Quick Details of 16Pin Connector Male female

3+13 Pin Partition Design for Isolated Transmission: Adopting a scientific 3+13 pin partition structure, the power channels and signal channels are physically isolated without crosstalk. 3 dedicated power pins provide stable main power supply, while 13 high-density signal pins support parallel transmission of multiple control signals, sensor data and communication commands. The integrated multi-channel design simplifies complex equipment wiring and solves the problem of insufficient interfaces for multi-signal devices.
300V High Withstand Voltage for Low-voltage Safety: Rated at 300V with sufficient electrical safety margin, the connector is perfectly suitable for various industrial and civil low-voltage working conditions. Optimized pin insulation spacing effectively prevents creepage, electric leakage and breakdown risks. It maintains long-term stable electrification and ensures dual safety of power supply and signal transmission.
Industrial-grade Modified PA66 Housing: Integrally injection-molded with high-quality modified PA66 nylon material, the housing features high rigidity, strong toughness and excellent compression and impact resistance. With UL94 V0 flame retardancy, superior insulation, temperature resistance, aging resistance and oil resistance, it adapts to harsh indoor and outdoor environments and delivers long service life.
Full-sealed Waterproof & Dustproof Protection: Equipped with high-elasticity integrated sealing ring and tightly fitted push-lock structure, the connector forms a fully closed protective barrier after docking. It effectively blocks rainwater, moisture, dust and oil intrusion, avoiding contact oxidation, poor connection and short circuit faults for all-weather stable operation in humid, dusty and outdoor scenarios.
Tool-free Anti-vibration Push Lock Structure: Featured with thread-free professional push-lock self-locking design, the male and female connectors can be automatically locked by simple pushing for tight and stable connection. Optimized for equipment vibration and external pulling, it is anti-loosening and anti-drop. Press-to-release design enables fast manual assembly and disassembly without tools, greatly improving production and maintenance efficiency.
Universal Matched Male & Female Connectors: Supplied with complete male and female matching sets for flexible cable extension, equipment transfer and line expansion. Adopting standard M25 industrial specification, it is highly compatible with mainstream matching accessories on the market, easy to replace and widely applicable for integrated docking of various low-voltage multi-signal electrical equipment.

Application industries

Communications Application
product coding machines
inventory product coding
inkjet systems
Solar System
industrial inkjet equipment
Electric power equipment
Laboratory forensic&pathology equipment
Communications equipment
Heavy machinery

Product Type Features
Connector System	Cable-to-Board
Sealable	Yes
Connector & Contact Terminates To	Wire & Cable
Circular Connector Type	Plug, Receptacle
Shell Type	Plastic Shell
Product Type	Connector Kit
Configuration Features
Number of Positions	3+13
Number of Signal Positions	13
Contacts Preloaded	Yes
Electrical Characteristics
Operating Voltage (VAC)	300V max.
Operating Voltage (VDC)	300V max.
Body Features
Shell Material	PA66
Circular Connector Insulation Material Type	Low Fire Hazard Thermoplastic
Hermetically Sealed	Yes
Entry Style	Side
Environmental Protection Type	Elastomer Sealed, Hermetically Sealed
O-Ring Material	Elastomer Sealed, Hermetically Sealed
Environmental Protection	Yes
Contact Features
Contact Current Rating (Max) (A) .	15A max.
Circular Connector Contact Type	Pin-Socket
Mechanical Attachment
Connector Mounting Type	Cable Mount (Free-Hanging)
Mating Alignment Type	Keyed
Mating Retention	With
Dimensions
Wire Size (AWG)	20AWG,18AWG,16AWG,14AWG,
Usage Conditions
Operating Temperature Range (°C)	-40 ~105°C
IP Water Sealing Level	IP67
IP Dust Sealing Level	6
Industry Standards
UL Flammability Rating	UL 94V-0

More Technical Details

3+13 Pin M25 Multi Pin Male Female Connector PA66 Waterproof 300V Push Lock Connector
