Detailed Product Description

Pin:	3+5Pin Power&data	Current Rating:	20A Max
Rated Voltage:	300V	Material:	Nylon
Protection Level:	IP67	Operating Temperature:	UL94-V0
Highlight:	M19 waterproof circular connector , 3+5 pin IP67 power connector , 20A plastic data connector

20A Plastic Circular M19 ODM Waterproof Power Data Connector 300V

Product Overview

Ulinkcon M19 3+5 Pin IP67 waterproof plastic circular connector is an ODM-supported integrated power and signal connector, rated at 300V and 15A+5A graded current. Featuring a professional 3+5 pin layout and full-plastic circular structure, it achieves stable high-current power supply and multi-channel signal transmission. With IP67 all-weather protection and strong environmental adaptability, it is a customizable and cost-effective connection solution for outdoor lighting, industrial control and smart equipment projects.

3+5 Pin Integrated Power & Signal Design:Adopts industry-standard 3+5 pin configuration for dual functions. 3 pins support 15A high-current power supply for equipment main load, while 5 independent pins undertake 5A low-voltage signal transmission. It integrates power and signal circuits in one connector, simplifying wiring and optimizing equipment assembly structure.
15A+5A Graded Load & 300V Insulation:Separated strong and weak current design matches different circuit loads accurately and avoids current crosstalk. 300V high voltage resistance resists outdoor voltage fluctuation and surge impact, effectively preventing electric leakage, short circuit and breakdown to ensure long-term safe equipment operation.
Professional ODM Customization Support:As a professional manufacturer, we provide full ODM customization services, including pin definition, cable specification, wire length, shell color and structural adjustment. Customizable solutions fit non-standard equipment and personalized engineering projects with higher flexibility than ordinary universal connectors.
Lightweight Full-Plastic Circular Structure:Adopts high-strength insulating plastic circular housing with no exposed metal parts. It features safe insulation, lightweight design, impact resistance and deformation resistance, suitable for external equipment docking and narrow installation spaces, improving overall equipment safety and appearance.
IP67 All-Weather Waterproof & Dustproof Performance:Equipped with high-precision elastic sealing gaskets for tight fitting and excellent cavity tightness. It effectively blocks rain splash, moisture, dust and sand ingress, maintaining stable connection performance in harsh all-weather outdoor working environments.
Anti-Interference & Industrial Durability:Physically isolated power and signal circuits eliminate electromagnetic interference, preventing signal delay, data distortion and light flicker. UV-resistant, temperature-resistant and anti-aging housing plus corrosion-resistant pins ensure long outdoor service life. Strict factory testing and mass customized delivery are available.

Electrical Specifications

Parameter	Specification
Number of Poles	3+5 Pin
Current Rating	15A +5Amax
Voltage Rating	300VAC max
Dielectric Strength	1500VAC @ 60 s

Technical Specifications

Parameter	Specification
Contact Resistance	10 mΩ max
Insulation Resistance	500 MΩ at 500VDC
Operating Temperature	-40°C to +105°C
IP Rating	IP67 (1m / 30min) when mated
Mold Material	PA66
Contact/Terminal Material	Gold Plated Brass
Seal Material	Silicone

Operation Parameters

Parameter	Specification
Voltage Rating	300VAC max
Current Rating	20A max
Wire Size OD (Min)	3.0mm - 6.0mm
Wire Size OD (Max)	8.0mm - 10.0mm
Max Cable Cross Section	0.5mm² - 2.5mm²

Configuration Options

Push lock quick release system
Multiple core options: 2Pin, 3Pin, 4Pin, 5Pin for Power
Power-signal combinations: 3+2Pin, 3+3Pin, 3+4Pin, 3+5Pin, 3+9Pin and 2+20Pin
Signal options: 6Pin, 7Pin, 8Pin, 9Pin, 10Pin, 11Pin, 12Pin, 14Pin, 16Pin and 18Pin
Field assembly versions: wire to wire and wire to board options
Current rated 20A for continuous operation
Cable assembly service supported with custom options
OEM/ODM services available

Application Industries

Growth Lights
Communications Equipment
Product Coding Machines
Inventory Product Coding Systems
Inkjet Systems
Solar Systems
Industrial Inkjet Equipment
Electric Power Equipment
Laboratory Forensic & Pathology Equipment
Heavy Machinery
