Name: M25 Waterproof Landscape Lighting Connectors 22 Pin Male To Female Cable Connectors
Brand: Shenzhen Ulinkcon Technology Co., Ltd.
SKU: M25
Availability: InStock

Home Products Waterproof LED Connector

M25 Waterproof Landscape Lighting Connectors 22 Pin Male To Female Cable Connectors

Product Details:

Place of Origin:	China
Brand Name:	Ulinkcon
Certification:	CE/Rohs/TUV/UL
Model Number:	M25

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiation
Price:	Negotiation
Packaging Details:	Box
Delivery Time:	5~8 working days
Payment Terms:	T/T,D/A,D/P,MoneyGram,L/C
Supply Ability:	100000 pairs each month

Contact Now

Detailed Product Description

Number Of Pins:	22Pin Waterproof Connector	Contact Material:	Brass Gold-Plated
Temperature Range:	-40℃~+105℃	Waterproof Rating:	IP67
Application:	Solar Panel	Color:	Red/Blue/Green

M25 Waterproof Landscape Lighting Connectors 22 Pin Male To Female Cable Connectors

Product Overview

M25 Power Signal Connector 2+20 Pin IP67 20A+5A Wire To Board Connector - Signal And Power Multi Connectors M25 2+20 Pin Waterproof 300 Volt Wire To Board

Key Features

2+20 Pin Specialized Division, Suitable for Landscape Lighting: Adopts a scientific 22-pin (2+20) layout with 2 pins for main power supply and 20 pins for landscape light control signal transmission. Accurately meets integrated "power supply + control" needs, eliminating additional connectors and simplifying landscape wiring.
High-Level Waterproof, Fearless of Outdoor Environments: Designed specifically for outdoor landscape scenarios with IP67 waterproof and dustproof rating. Precision silicone sealing structure effectively resists rain immersion, dew condensation, and outdoor dust interference for stable long-term operation.
Male & Female Mating Design, Easy Installation: Convenient male and female mating structure requires no professional tools and enables accurate manual connection. Stable, anti-falling connection suitable for on-site wiring, maintenance, and lamp replacement.

Application Industries

Communications Equipment
Product Coding Machines & Inkjet Systems
Solar Systems
Electric Power Equipment
Laboratory Forensic & Pathology Equipment
Heavy Machinery
Industrial Inkjet Equipment

Technical Specifications

Electrical Parameters

Number of Poles	22pin wire to board connector
Current Rating	20A
Voltage Rating	300VAC max
Durability Voltage	2500VAC @ 60 s

Technical Parameters

Contact Resistance	10 mΩ max
Insulation Structure	500 MΩ at 500VDC
Operating Temperature	-40°C ~ +105°C
IP Class	IP67 (1m / 30min)
Mold Material	PA66
Contact/Terminal Material	Gold Plated Brass
Seal Material	Silicone

Operation Parameters

Voltage Rating	600VAC max
Current Rating	20A max
Min Wire Size OD	6.5mm ~ 10mm
Max Wire Size OD	10.5mm ~ 18mm
Max Cable Cross Section Area	0.5mm² ~ 6.0mm²

Product Configuration

Product Dimension

Technical Details

Frequently Asked Questions

What is rated voltage?

Rated voltage, also known as operating voltage, depends on the connector insulation material used and the spacing between contact sizes. Some components or devices may not function properly below their rated voltage.

What shipping methods do you offer? How long is the delivery time?

We provide multiple shipping options: 1) Courier (DHL/UPS/FedEx): 3 - 7 working days for small parcels; 2) Air freight: 7 - 15 working days; 3) Sea freight: 20 - 45 working days. Delivery time varies by destination and shipping method.

How to track my shipment?

Once goods are shipped, we provide tracking numbers and logistics platform links. You can track real-time status online or contact our team for updates.
