Designed specifically for DC power supply scenarios, the M16 5-pin Wire-to-Wire Waterproof Quick-Lock Connector features easy installation, reliable protection and customized adaptation as its core advantages, making it a preferred connection accessory for outdoor and industrial DC equipment. Complying with the M16 standard interface, the precision 5-pin layout adapts to DC power transmission needs. The wire-to-wire connection mode enables direct cable docking without intermediate components, simplifying connections and improving power supply stability.
The quick-lock mechanism is a core feature of this product. Plugging, pulling and locking can be completed with bare hands. It locks firmly after insertion, easily coping with scenarios such as outdoor wind sway and equipment operation vibration, preventing power interruption caused by accidental detachment. The waterproof performance is top-notch. Through professional sealing structure design, it effectively blocks erosion from rain, sand dust, moisture, and can work stably even in complex and harsh environments, ensuring all-weather normal operation of DC equipment.
The body is made of high-quality materials. The conductor has excellent conductivity and strong oxidation resistance, ensuring efficient and low-consumption DC power transmission. The shell has outstanding insulation performance, good impact resistance and anti-aging effect, adapting to various working conditions such as long-term outdoor exposure and industrial workshop wear. ODM full-process customization is supported, and product details can be adjusted according to the customer's actual application scenarios and equipment parameters. It is widely applicable to outdoor sensors, DC lighting, small new energy equipment, industrial control DC power supply systems and other scenarios, providing exclusive connection solutions for different needs.
Key Features
- Push-lock quick release system
- Multiple core options: 2Pin, 3Pin, 4Pin, 5Pin, 2+4Pin, 7Pin, 8Pin
- Field assembly version supports both wire-to-wire and wire-to-board connections
- High current rating up to 8A for continuous operation
- Cable assembly service available for custom requirements
- OEM/ODM services supported
Electrical Parameters
| Number of Poles |
5Pin waterproof connector |
| Current Rating |
8A max |
| Voltage Rating |
125VAC max |
| Durability Voltage |
500VAC @ 60 s |
Technical Parameters
| Contact Resistance |
10 mΩ max |
| Insulation Structure |
500 MΩ at 500VDC |
| Operating Temperature |
-40°C ~ +105°C |
| IP Class |
IP67 (1m / 30min) |
| Mold Material |
PA66 |
| Contact/Terminal Material |
Gold Plated Brass |
| Seal Material |
Silicone |
Application Industries
- Communications equipment
- Product coding machines
- Inventory product coding systems
- Inkjet systems
- Solar power systems
- Industrial inkjet equipment
- Electric power equipment
- Laboratory forensic & pathology equipment
- Heavy machinery
Production Dimension
Professional Manufacturer
Frequently Asked Questions
Q1: Are you a factory or trading company?
A1: We are a factory. Located in Ulinkcon Industrial Park, Bao'an District, Shenzhen, China
Q2: How many materials you can provide?
A2: There are different materials available for connectors and cables. We typically use PVC/Nylon material for connectors, and PVC/Rubber/Silicone materials for cables. We can also select materials according to your specific requirements.
Q3: How to choose the suitable connector?
A3: Follow these steps:
- Confirm current rating and number of contacts needed
- Determine if pre-cable assembly is required
- Specify cable gauge
- Determine required cable length and material
