M19 High Current Wire To Board Connector 300V Male Female Connector 4 Pin

Product Details:

Place of Origin:	China
Brand Name:	Ulinkcon
Certification:	CE/Rohs/TUV/UL
Model Number:	M19

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiation
Price:	Negotiation
Packaging Details:	1.Plastic bag;2.Carton;3.As per customer's requirements
Delivery Time:	3~6working days
Payment Terms:	T/T,D/P,L/C,D/A,,Western Union,MoneyGram
Supply Ability:	100000 pairs Montly

Contact Now

Detailed Product Description

Current Rating:	15A	Rated Voltage:	300V
Connector Type:	Quick Connector	Material:	Nylon
Color:	Red Blue White Black Yellow	Flame-resistant Rating:	UL94-V0
Highlight:	M19 waterproof power connector 4 pin , high current wire to board connector , 300V male female connector

M19 High Current Wire To Board Connector 300V Male Female Connector 4 Pin

IP67 Waterproof M19 4 Pin Male To Female Outdoor Connector

The M19 series 4Pin Wire-to-Board (WTB) male and female connector is engineered for high-current transmission applications, featuring a 15A current rating and 300V voltage rating. Its robust construction and stable electrical performance make it an ideal solution for industrial and equipment connections. The male-female pairing design ensures reliable connections between wires and circuit boards, while the 4-pin configuration meets signal and power transmission requirements for medium to high-power equipment.

Constructed with glass fiber-reinforced nylon housing compliant with UL94 V0 flame-retardant standards, this connector offers exceptional high-temperature resistance, corrosion resistance, and insulation properties. It operates reliably in temperature environments ranging from -40℃ to 105℃. The high-conductivity brass contacts with gold plating feature contact resistance below 10mΩ, insulation resistance exceeding 500mΩ, and withstand voltage up to 1000V, ensuring minimal loss and heat generation during high-current transmission.

Featuring optional push-pull self-locking or plastic thread fixing mechanisms, the connector maintains secure connections even in industrial vibration environments. Compliant with RoHS environmental standards and certified by CE and UL, it finds applications across industrial automation equipment, power modules, LED displays, medical devices, and new energy systems.

Main Features

Push lock quick release system
Multiple pin configurations: 2Pin, 3Pin, 4Pin, 5Pin for power
Combined power and signal options: 3+2Pin, 3+3Pin, 3+4Pin, 3+5Pin, 3+9Pin and 2+20Pin
Signal-only options: 6Pin through 18Pin available
Field assembly versions for wire-to-wire and wire-to-board applications
15A current rating for continuous operation
Cable assembly services available
OEM/ODM customization welcome

Electrical Parameters

Number of Poles	4Pin
Current Rating	15A max.
Voltage Rating	300VAC max
Durability Voltage	1000VAC @ 60 s.

Technical Parameters

Contact Resistance	10 mΩ max
Insulation Structure	500 MΩ at 500VDC
Operating Temperature	-40°C ~ +105°C
IP Class	IP67 (1m / 30min) when mated
Mold Material	PA66
Contact/Terminal Material	Gold Plated Brass
Seal Material	Silicone

Operation Parameters

Voltage Rating	600VAC max
Current Rating	15A max
Min Wire Size OD	3.0mm ~ 6.0mm
Max Wire Size OD	8.0mm ~ 10.0mm
Max Cable Cross Section Area	0.5mm² ~ 2.5mm²

Application Industries

Growth Lights
Communications Equipment
Product Coding Machines
Inventory Product Coding Systems
Inkjet Systems
Solar Systems
Industrial Inkjet Equipment
Electric Power Equipment
Laboratory Forensic & Pathology Equipment
Communications Equipment
Heavy Machinery

Product Design

Frequently Asked Questions

Are you a factory or trading company?

We are a factory located in Ulinkcon Industrial Park, Bao'an District, Shenzhen, China.

What is rated voltage?

Rated voltage, also known as operating voltage, depends primarily on the connector's insulation material and contact spacing. Some components may not function properly below their rated voltage.

How can I get samples?

We are pleased to provide samples, with freight costs to be covered by the customer. Please provide your courier account number and detailed address for sample shipment.

Can I have custom labeling?

Yes, we support private labeling and custom packaging. Our professional design team is available to assist with packaging design requirements.
