Name: M16 5 Pin Male Female Connector 300V Waterproof For Heavy-Duty Application
Brand: Shenzhen Ulinkcon Technology Co., Ltd.
SKU: M16
Availability: InStock

Home Products Waterproof Circular Connector

M16 5 Pin Male Female Connector 300V Waterproof For Heavy-Duty Application

Product Details:

Place of Origin:	China
Brand Name:	Ulinkcon
Certification:	CE/Rohs
Model Number:	M16

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiation
Price:	Negotiation
Packaging Details:	High Quality export carton
Delivery Time:	3~6 working days
Payment Terms:	T/T,D/A,D/P,MoneyGram,L/C
Supply Ability:	100000 pairs each month

Contact Now

Detailed Product Description

Number Of Pins:	5Pin	Current:	8A Max. For Power
Rated Voltage:	125V	Waterproof Rating:	IP67
Operating Temperature:	-40℃~+105℃	Contact Material:	Brass Gold-Plated
Highlight:	M16 waterproof circular connector , 5 pin heavy-duty connector , 300V waterproof male female connector

M16 5 Pin Male Female Connector 300V Waterproof For Heavy-Duty Application

M16 5 Pin 300V Push Lock Waterproof Connector IP67 For Heavy-Duty Application
8A 5Pin Waterproof Circular Connector, Quick Release Male To Female Wire Connector

Engineered for heavy-duty industrial applications, this M16 5-pin connector supports 300V stable power/signal transmission. Boasting reliable waterproof performance, it resists dust, moisture and oil erosion, with secure male-female docking that fits harsh working conditions like industrial automation and outdoor equipment.

Key Features

Push-lock quick release system
Multiple core : 2Pin, 3Pin, 4Pin, 5Pin, 2+4Pin, 7Pin, 8Pin
Field assembly version supports both wire-to-wire and wire-to-board connections
High current rating up to 8A for continuous operation
Cable assembly service available for custom requirements
OEM/ODM services supported

Electrical Parameters

Parameter	Specification
Number of Poles	5Pin waterproof connector
Current Rating	8A max
Voltage Rating	125VAC max
Durability Voltage	500VAC @ 60 s

Technical Parameters

Parameter	Specification
Contact Resistance	10 mΩ max
Insulation Structure	500 MΩ at 500VDC
Operating Temperature	-40°C ~ +105°C
IP Class	IP67 (1m / 30min)
Mold Material	PA66
Contact/Terminal Material	Gold Plated Brass
Seal Material	Silicone

Application Industries

Communications equipment
Product coding machines
Inventory product coding systems
Inkjet systems
Solar power systems
Industrial inkjet equipment
Electric power equipment
Laboratory forensic & pathology equipment
Heavy machinery

Production Dimension

Professional Manufacturer

Frequently Asked Questions

Q1: Are you a factory or trading company?

A1: We are a factory. Located in Ulinkcon Industrial Park, Bao'an District, Shenzhen, China

Q2: How many materials you can provide?

A2: There's some different materials from connector and cable, we usually use PVC/Nylon material to product connector, PVC/Rubber/Silicone material was used in cable. Of course we can also according to your requirements to choose the material.

Q3: What shipping methods do you offer? How long is the delivery time?

A3: We provide multiple shipping options: 1) Courier (DHL/UPS/FedEx): 3 - 7 working days for small parcels; 2) Air freight: 7 - 15 working days; 3) Sea freight: 20 - 45 working days. Delivery time varies by destination and shipping method.

Ratings & Review

Overall Rating

5.0

Based on 50 reviews for this supplier

Rating Snapshot

The following is the distribution of all ratings

5 stars

100%

4 stars

3 stars

2 stars

1 stars

All Reviews

J*s

Greece Jul 27.2025

Helpful (1337)

Before purchase, I had doubts about waterproof performance in heavy rain. The seller explained everything patiently and even shared real use cases. After sales, they replied quickly when I had small questions. The connectors work really well in our monsoon season—excellent service and product.

M*e

Mexico May 10.2025

Helpful (756)

Great experience from start to finish. I had a lot of questions about IP rating and material, and the customer service was super helpful—they explained everything clearly and professionally. The ordering system was straightforward, shipping was faster than expected, and the product quality matched the description perfectly.

M*n

United States Nov 28.2024

Helpful (1160)

We’ve ordered these waterproof connectors three times already. They work great for outdoor LED lighting and industrial equipment. We’ve had no water ingress issues at all, even during heavy rain. The bulk price is good, shipping is fast, and the seller is very responsive. We’ll keep buying.
