Name: 2+20 Pin Wire To Board Cable Connectors M20 Multi Pin IP67 Solar Connectors
Brand: Shenzhen Ulinkcon Technology Co., Ltd.
SKU: M19
Availability: InStock

Home Products Multi Pin Connectors Waterproof

2+20 Pin Wire To Board Cable Connectors M20 Multi Pin IP67 Solar Connectors

Product Details:

Place of Origin:	China
Brand Name:	Ulinkcon
Certification:	CE/Rohs/TUV/UL
Model Number:	M19

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiation
Price:	Negotiation
Packaging Details:	1.Plastic bag;2.Carton;3.As per customer's requirements
Delivery Time:	3~6working days
Payment Terms:	T/T,D/P,L/C,D/A,,Western Union,MoneyGram
Supply Ability:	100000 pairs Montly

Contact Now

Detailed Product Description

Material:	PA66&Copper Alloy	Rated Voltage:	300V
Color:	White Blue Red Black Yellow	Protection Level:	IP67
Flame-resistant Rating:	UL94-V0	Contact Material:	Brass Gold-Plated
Highlight:	2+20 pin wire to board connector , M20 multi pin IP67 connector , waterproof solar cable connector

Waterproof Multi 2 Pin For Power Connectors M19 300V Push Locking 20 Pin Data Connector

Quick Description

Dual-Purpose Power & Data Pin Layout

Featuring a specialized 2-pin power section for reliable 300V power supply and a 20-pin data section for high-speed, low-noise signal transfer, this connector’s separated pin design eliminates cross-interference between circuits. This ensures both steady energy delivery and accurate data transmission—critical for the seamless operation of complex integrated systems.

IP67 Waterproof & Dustproof Performance for Versatile Use

With precision-molded sealing gaskets and a rugged M19 housing, the connector meets the IP67 protection standard, effectively shielding against rain, splashes, and dust buildup. It performs reliably in a wide range of challenging environments, from damp factory floors and outdoor equipment stations to corrosive marine settings.

Quick-Lock Push Mating for Effortless, Secure Installation

The intuitive push-locking mechanism allows for tool-free, one-handed connection: a simple push until a "click" sound ensures a tight, secure lock between male and female connectors. This user-centric design reduces installation time by 40% versus threaded alternatives and prevents accidental disconnections due to vibration, impact, or unintended cable pulls.

Industrial-Grade Durability & Signal Integrity

Power pins are made of silver-plated copper alloy with superior conductivity, efficiently supporting 300V loads. Data pins, meanwhile, use gold-plated copper alloy to minimize contact resistance, ensuring that high-speed signals are transmitted without errors—even during long-term use in harsh industrial conditions.

Application industries

Growth Lights
Communications Application
product coding machines
inventory product coding
inkjet systems
Solar System
industrial inkjet equipment
Electric power equipment
Laboratory forensic&pathology equipment
Communications equipment
Heavy machinery

Electrical Parameters
Number of Poles	2pin waterproof connector
Current Rating	20A max.
Voltage Rating	300VAC max
Durability Voltage	1500VAC @ 60 s.

Technical Parameters
Contact Resistance	10 mΩ max
Insulation Structure	500 MΩ at 500VDC
Operating Temperature	-40°C ~ +105°C
IP Class	IP67 (1m / 30min) when mated
Mold Material	PA66
Contact/Terminal Material	Gold Plated Brass
Seal Material	Silicone

Operation Parameters
Voltage Rating	600VAC max
Current Rating	20A max
Min Wire Size OD	3.0mm ~ 6.0mm
Max Wire Size OD	8.0mm ~ 10.0mm
Max.Cable Cross Section Area	0.5mm² ~ 2.5mm²

Design Sketch

2+20 Pin Wire To Board Cable Connectors M20 Multi Pin IP67 Solar Connectors 1
