Name: M25 Waterproof Connector Wire To Board 3+9 Pin Data Power Connector PA66 Outdoor
Brand: Shenzhen Ulinkcon Technology Co., Ltd.
SKU: M25
Availability: InStock

Home Products Outdoor Waterproof Connector

M25 Waterproof Connector Wire To Board 3+9 Pin Data Power Connector PA66 Outdoor

Product Details:

Place of Origin:	China
Brand Name:	Ulinkcon
Certification:	CE/Rohs
Model Number:	M25

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiation
Price:	Negotiation
Packaging Details:	Box
Delivery Time:	5~8 working days
Payment Terms:	T/T,D/A,D/P,MoneyGram,L/C
Supply Ability:	100000 pairs each month

Contact Now

Detailed Product Description

Number Of Pins:	3+9 PIN	Current:	15A
Waterproof Rating:	IP67	Temperature Range:	-40℃~+105℃
Material:	Nylon	Flame-resistant Rating:	UL94-V0
Highlight:	M25 waterproof wire to board connector , 3+9 pin waterproof power connector , PA66 outdoor waterproof data connector

M25 Waterproof Connector Wire To Board 3+9 Pin Data Power Connector PA66 Outdoor

Multi Pin Connector Types Of 3+9 Pin M25 30A 300V Outdoor Waterproof Connector

Main Features

Push lock quick release system
Multic-core options: 2Pin, 3Pin, 4Pin, 5Pin, 3+2Pin, 3+3Pin, 3+9Pin, 3+13Pin and 2+20Pin
Field assembly version: both wire to wire and wire to board options
Current rated 20A for long time working
Cable assembly service supported, welcome to custom
OEM/ODM welcome

Application Industries

Communications Application
Product coding machines
Inventory product coding
Inkjet systems
Solar System
Industrial inkjet equipment
Electric power equipment
Laboratory forensic & pathology equipment
Communications equipment
Heavy machinery

Key Technical Features

3+9 Pin Composite Design: Separates power and data signal transmission to avoid interference, meeting the simultaneous power supply and data communication needs of equipment.
PA66 High-Strength Housing: Boasts excellent weather resistance, corrosion resistance and impact resistance, capable of withstanding harsh outdoor environments such as high and low temperatures and UV radiation.
IP67 Waterproof Rating: Professional waterproof structural design effectively prevents rainwater and dust intrusion, suitable for outdoor security, industrial control, new energy equipment and other scenarios.
Quick Plug-in & Locking: Snap-in connection structure enables convenient plugging and unplugging with stable connection, preventing vibration-induced loosening and improving installation efficiency.

Technical Specifications

Product Type Features	Cable-to-Board
Sealable	Yes
Connector & Contact Terminates To	Wire & Cable
Circular Connector Type	Plug, Receptacle
Shell Type	Plastic Shell
Product Type	Connector Kit
Configuration Features	3+9 positions, 9 signal positions, contacts preloaded
Electrical Characteristics	600V max. (AC/DC)
Body Features	PA66 shell material, low fire hazard thermoplastic, hermetic sealing
Contact Features	15A max. current rating, pin-socket contact type
Mechanical Attachment	Cable mount (free-hanging), keyed mating alignment, with mating retention
Dimensions	Wire Size: 20AWG, 18AWG, 16AWG, 14AWG
Usage Conditions	Operating Temperature: -40°C to 105°C, IP67 Water Sealing, IP6 Dust Sealing
Industry Standards	UL 94V-0 Flammability Rating

Production Dimension

Technical Details

Frequently Asked Questions

Q1: What is rated voltage?

A1: Rated voltage also known as operating voltage, which mainly depend on the connector insulation material used, the spacing between the size of contact. Some of the components or devices in less than its rated voltage may not be completed to its functions.

Q2: What if there are quality issues with the received goods?

A2: Please provide photos/videos of the defective products within 7 days of receipt. We will verify the issue and offer solutions such as free replacement, repair, or partial refund based on the situation.

Q3: Are you a factory or trading company?

A3: We are a factory. Located in Ulinkcon Industrial Park, Bao'an District, Shenzhen, China
