Name: M16 Waterproof Circular Connector 300V 2 Pin Male To Female Cable Connectors
Brand: Shenzhen Ulinkcon Technology Co., Ltd.
SKU: M16
Availability: InStock

Home Products Waterproof Circular Connector

M16 Waterproof Circular Connector 300V 2 Pin Male To Female Cable Connectors

Product Details:

Place of Origin:	China
Brand Name:	Ulinkcon
Certification:	CE/Rohs
Model Number:	M16

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiation
Price:	Negotiation
Packaging Details:	High Quality export carton
Delivery Time:	3~6 working days
Payment Terms:	T/T,D/A,D/P,MoneyGram,L/C
Supply Ability:	100000 pairs each month

Contact Now

Detailed Product Description

Number Of Pins:	2Pin	Current:	10A Max. For Power
Rated Voltage:	300V	Waterproof Rating:	IP67
Flame-resistant Rating:	UL94-V0	Color:	Blue/Green/Yellow/Red
Highlight:	M16 waterproof circular connector 2 pin , 300V waterproof male to female connector , M16 waterproof cable connector with warranty

2 Pin Circular Power Connector M16 300V Waterproof Male Female Wire Connector

Description of Industrial Waterproof Circular Connector

2 Pin Core Specifications and Connection Mode: Adopts a 2 Pin male-to-female plug-in design, focusing on the cable-to-cable connection mode, suitable for 300V rated voltage scenarios, and can stably meet the power transmission needs of small and medium-power equipment; it follows the M16 interface standard, with a compact circular structure, accurate pin alignment, smooth plugging and small connection gap, ensuring the stability of power transmission.

Professional Waterproof Sealing Performance: Equipped with a high-standard waterproof structure, the connection between the circular shell and the cable adopts an integrated sealing process with a custom waterproof rubber ring, which can effectively resist erosion from rainwater, sand, oil stains and humid environments. It is suitable for outdoor open-air operations or complex working scenarios with high moisture and dust, greatly reducing the risk of short circuits, poor contact and other faults caused by environmental factors.

Exclusive Advantages of Cable-To-Cable Connection: Tailor-made for cable-to-cable connection scenarios, the male and female plugs are firmly fixed to the cable without loose hidden dangers, and can resist slight pulling and vibration during equipment operation or movement; no complex installation tools are required, and on-site plug-in operation is convenient and efficient, adapting to high-frequency operation needs such as temporary equipment docking, later maintenance and cable extension.

300V Adaptive Materials and Safety Performance: The conductor is made of high-conductivity oxygen-free copper, and the surface is anti-oxidation tinned, which can effectively reduce heat generation and loss under 300V voltage transmission, ensuring efficient power transmission; the shell is made of high-insulation grade engineering plastic, which has excellent aging resistance and impact resistance, and can isolate electromagnetic interference, eliminating potential safety hazards such as electric leakage and power leakage, complying with industrial safe operation standards.

Diversified Scenario Adaptation Range: Widely used in scenarios requiring cable-to-cable power connections such as industrial control equipment, security monitoring systems, smart home appliances, new energy auxiliary equipment, and instruments and meters; it is especially suitable for small and medium-power equipment that requires connection convenience and waterproof performance, such as outdoor sensors, portable instruments, small automation components, etc., providing reliable connection support for stable equipment operation.

Main Feature

Push lock quick easy release system
Multi-core can be choosen: 2Pin, 3Pin, 4Pin, 5Pin, 2+4Pin, 7Pin, 8Pin
Field-installable variants: both wire-to-wire and wire-to-board configurations
High-current-rated waterproof connector: an ideal solution for prolonged operation up to 10A
Cable assembly services provided – customization is welcome
OEM/ODM partnerships are warmly accepted

Electrical Parameters
Number of Poles	2Pin waterproof connector
Current Rating	10A max
Voltage Rating	300VAC max
Durability Voltage	1500VAC @ 60 s.

Technical Parameters
Contact Resistance	10 mΩ max
Insulation Structure	500 MΩ at 500VDC
Operating Temperature	-40°C ~ +105°C
IP Class	IP67 (1m / 30min)
Mold Material	PA66
Contact/Terminal Material	Gold Plated Brass
Seal Material	Silicone

Application industries

Communications Application
product coding machines
inventory product coding
inkjet systems
Solar System
industrial inkjet equipment
Electric power equipment
Laboratory forensic&pathology equipment
Communications equipment
Heavy machinery

Production Dimension

M16 Waterproof Circular Connector 300V 2 Pin Male To Female Cable Connectors 0

More Technical Details

M16 Waterproof Circular Connector 300V 2 Pin Male To Female Cable Connectors 1

M16 Waterproof Circular Connector 300V 2 Pin Male To Female Cable Connectors 2

FAQ

Q1:How can I get samples?

A1:It's my honor to offer you samples,and the freight should be paied by yourself.You can let me know your courier number and your detail address,Then I can send you sample at once.

Q2:Are your products certified? What certifications do you have?

A2: All our products are certified by RoHS, CE, and other international standards. Specific certifications (e.g., FCC, UL) can be provided upon request based on your target market.

Q3:What shipping methods do you offer? How long is the delivery time?

A3: We provide multiple shipping options: 1) Courier (DHL/UPS/FedEx): 3 - 7 working days for small parcels; 2) Air freight: 7 - 15 working days; 3) Sea freight: 20 - 45 working days. Delivery time varies by destination and shipping method.
