Name: Panel Mount Circular Connector M25 16 Pin ODM 3 Power 13 Signal Waterproof Connector
Brand: Shenzhen Ulinkcon Technology Co., Ltd.
SKU: M25
Availability: InStock

Home Products Waterproof Plug Socket

Panel Mount Circular Connector M25 16 Pin ODM 3 Power 13 Signal Waterproof Connector

Product Details:

Place of Origin:	China
Brand Name:	Ulinkcon
Certification:	CE/Rohs
Model Number:	M25

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiation
Price:	Negotiation
Packaging Details:	Box
Delivery Time:	5~8 working days
Payment Terms:	T/T,D/A,D/P,MoneyGram,L/C
Supply Ability:	100000 pairs each month

Contact Now

Detailed Product Description

Number Of Pins:	3+13PIN	Current:	15A+5A
Waterproof Rating:	IP67	Temperature Range:	-40℃~+105℃
Connection:	Wire To Board	Flame-resistant Rating:	UL94-V0
Highlight:	M25 waterproof circular connector , 16 pin panel mount connector , ODM waterproof plug socket

3+13 Pin Plug Socket Waterproof M25 Data And Power Connector IP67,Quick Locking

Main Features

Push lock quick release system
Multic-core options: 2Pin,3Pin,4Pin,5Pin,3+2Pin,3+3Pin,3+9Pin,3+13Pin and 2+20Pin
Field assembly version:both wire to wire and wire to board options
Current rated 20A for long time working
Cable assembly service supported, welcome to custom
OEM/ODM welcome

Quick Details of 16Pin Connector Male female

16 Pin 3+13 Separated Core Specifications: Adopts a 16 Pin (3-pin power + 13-pin signal) separated design. The 13-pin signal channel can meet the needs of simultaneous transmission of multiple groups of precision signals, and the 3-pin power channel is suitable for industrial-grade power supply scenarios, avoiding cross-interference between power supply and signals from the structure. It follows the M25 interface standard, features a circular connector structure, and is compatible with panel mount mode. The pins are accurately aligned to ensure connection stability after installation.

Professional Waterproof Performance and Circular Structure Advantages: Equipped with a high-standard waterproof sealing design, the circular shell is matched with a custom waterproof rubber ring, which can effectively resist erosion from rainwater, sand, oil stains and humid environments, making it suitable for outdoor open-air equipment or dusty industrial scenarios. The circular structure not only facilitates panel hole drilling and installation but also has stronger impact resistance and torsion resistance, which can adapt to slight vibrations during long-term equipment operation and reduce the risk of connection failures.

Exclusive Adaptive Design for Panel Mount: Tailor-made for panel mount scenarios, it is equipped with standardized mounting buckles and fixed holes, enabling convenient and efficient installation that can be quickly integrated into the panels of various industrial equipment. After installation, it fits closely with the panel without loose gaps, which not only ensures connection firmness but also improves the overall aesthetics of the equipment, adapting to the integrated design needs of industrial equipment.

ODM Customization Service Capability: Supports ODM customization services, which can adjust product details according to specific customer needs, including but not limited to interface locking methods, terminal materials, waterproof grade enhancement, and shell color customization. The customization process strictly follows industrial quality standards to ensure that customized products meet the personalized application needs of customers in different industries in terms of performance and compatibility.

Application industries

Communications Application
product coding machines
inventory product coding
inkjet systems
Solar System
industrial inkjet equipment
Electric power equipment
Laboratory forensic&pathology equipment
Communications equipment
Heavy machinery

Product Type Features
Connector System	Cable-to-Board
Sealable	Yes
Connector & Contact Terminates To	Wire & Cable
Circular Connector Type	Plug, Receptacle
Shell Type	Plastic Shell
Product Type	Connector Kit
Configuration Features
Number of Positions	3+13
Number of Signal Positions	13
Contacts Preloaded	Yes
Electrical Characteristics
Operating Voltage (VAC)	300V max.
Operating Voltage (VDC)	300V max.
Body Features
Shell Material	PA66
Circular Connector Insulation Material Type	Low Fire Hazard Thermoplastic
Hermetically Sealed	Yes
Entry Style	Side
Environmental Protection Type	Elastomer Sealed, Hermetically Sealed
O-Ring Material	Elastomer Sealed, Hermetically Sealed
Environmental Protection	Yes
Contact Features
Contact Current Rating (Max) (A) .	15A max.
Circular Connector Contact Type	Pin-Socket
Mechanical Attachment
Connector Mounting Type	Cable Mount (Free-Hanging)
Mating Alignment Type	Keyed
Mating Retention	With
Dimensions
Wire Size (AWG)	20AWG,18AWG,16AWG,14AWG,
Usage Conditions
Operating Temperature Range (°C)	-40 ~105°C
IP Water Sealing Level	IP67
IP Dust Sealing Level	6
Industry Standards
UL Flammability Rating	UL 94V-0

More Technical Details
