Name: M16 5 Pin 300V Push Lock Waterproof Circular Connector IP67 For Heavy-Duty Applications
Brand: Shenzhen Ulinkcon Technology Co., Ltd.
SKU: M16
Availability: InStock

Home Products Waterproof Circular Connector

M16 5 Pin 300V Push Lock Waterproof Circular Connector IP67 For Heavy-Duty Applications

Product Details:

Place of Origin:	China
Brand Name:	Ulinkcon
Certification:	CE/Rohs
Model Number:	M16

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiation
Price:	Negotiation
Packaging Details:	High Quality export carton
Delivery Time:	3~6 working days
Payment Terms:	T/T,D/A,D/P,MoneyGram,L/C
Supply Ability:	100000 pairs each month

Contact Now

Detailed Product Description

Number Of Pins:	5Pin	Current:	8A Max. For Power
Rated Voltage:	125V	Waterproof Rating:	IP67
Color:	Blue Red Black White Yellow	Operating Temperature:	-40℃~+105℃
Highlight:	M16 waterproof circular connector IP67 , 5 pin push lock connector 300V , heavy-duty waterproof circular connector

M16 5 Pin 300V Push Lock Waterproof Circular Connector IP67 For Heavy-Duty Applications

8A 5Pin Waterproof Circular Connector, Quick Release Male To Female Wire Connector

Industrial Waterproof Circular Connector

This M16 model connectors is specialized for various power signal comblined applications, easy ooperation design in push locking system, just need a second to insert, then it will lock automatically.
Power & Singal together in one set design is getting more and more popular to many device, which solve the power and signal connector separated using perfectly, especially for the space limited application.
Cable assembly available for Multi pin Connectors is supported in Ulinkcon,just please share cable request in details, custom service available.

Key Features

Push-lock quick release system
Multiple core : 2Pin, 3Pin, 4Pin, 5Pin, 2+4Pin, 7Pin, 8Pin
Field assembly version supports both wire-to-wire and wire-to-board connections
High current rating up to 10A for continuous operation
Cable assembly service available for custom requirements
OEM/ODM services supported

Electrical Parameters

Number of Poles	5Pin waterproof connector
Current Rating	8A max
Voltage Rating	125VAC max
Durability Voltage	500VAC @ 60 s

Technical Parameters

Contact Resistance	10 mΩ max
Insulation Structure	500 MΩ at 500VDC
Operating Temperature	-40°C ~ +105°C
IP Class	IP67 (1m / 30min)
Mold Material	PA66
Contact/Terminal Material	Gold Plated Brass
Seal Material	Silicone

Application Industries

Communications equipment
Product coding machines
Inventory product coding systems
Inkjet systems
Solar power systems
Industrial inkjet equipment
Electric power equipment
Laboratory forensic & pathology equipment
Heavy machinery

Production Dimension

M16 5 Pin 300V Push Lock Waterproof Circular Connector IP67 For Heavy-Duty Applications 0

Professional Manufacturer

M16 5 Pin 300V Push Lock Waterproof Circular Connector IP67 For Heavy-Duty Applications 1

Frequently Asked Questions

Q1: Are you a factory or trading company?

A1: We are a factory. Located in Ulinkcon Industrial Park, Bao'an District,Shenzhen,China

Q2: How many materials you can provide?

A2:There's some different materials from connector and cable, we usually use PVC/Nylon material to product connector, PVC/Rubber/Silicone material was used in cable. Of course we can also according to your requirments to choose the material.

Q3: How to choose the suitable connector?

A3: Follow these steps:

Confirm current rating and number of contacts needed
Determine if pre-cable assembly is required
Specify cable gauge
Determine required cable length and material
