Name: M16 5 Pin 300V Push Lock Waterproof Circular Connector IP67 For Heavy-Duty Applications
Brand: Shenzhen Ulinkcon Technology Co., Ltd.
SKU: M16
Availability: InStock

Home Products Waterproof Circular Connector

M16 5 Pin 300V Push Lock Waterproof Circular Connector IP67 For Heavy-Duty Applications

Product Details:

Place of Origin:	China
Brand Name:	Ulinkcon
Certification:	CE/Rohs
Model Number:	M16

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiation
Price:	Negotiation
Packaging Details:	High Quality export carton
Delivery Time:	3~6 working days
Payment Terms:	T/T,D/A,D/P,MoneyGram,L/C
Supply Ability:	100000 pairs each month

Contact Now

Detailed Product Description

Number Of Pins:

5Pin

Current:

8A Max. For Power

Rated Voltage:

125V

Waterproof Rating:

IP67

Highlight:

IP67 Waterproof Circular Connector

5 Pin Waterproof Circular Connector

300V Waterproof Circular Connector

M16 5 Pin 300V Push Lock Waterproof Circular Connector IP67 For Heavy-Duty Applications

8A 5Pin Waterproof Circular Connector, Quick Release Male To Female Wire Connector

Industrial Waterproof Circular Connector

This connector is designed for various power applications with an easy-to-use push locking system that automatically secures upon insertion. Available with both screw terminals and soldering terminals for flexible installation options.

The screw terminal version enables quick field assembly without soldering, making it ideal for creating custom waterproof connection cables. The soldering terminal option provides reliable connections for applications requiring soldered joints.

Key Features

Push-lock quick release system for easy operation
Multiple core options available: 2Pin, 3Pin, 4Pin, 5Pin, 2+4Pin, 7Pin, 8Pin
Field assembly version supports both wire-to-wire and wire-to-board connections
High current rating up to 10A for continuous operation
Cable assembly service available for custom requirements
OEM/ODM services supported

Electrical Parameters

Number of Poles	5Pin waterproof connector
Current Rating	8A max
Voltage Rating	125VAC max
Durability Voltage	500VAC @ 60 s

Technical Parameters

Contact Resistance	10 mΩ max
Insulation Structure	500 MΩ at 500VDC
Operating Temperature	-40°C ~ +105°C
IP Class	IP67 (1m / 30min)
Mold Material	PA66
Contact/Terminal Material	Gold Plated Brass
Seal Material	Silicone

Application Industries

Communications equipment
Product coding machines
Inventory product coding systems
Inkjet systems
Solar power systems
Industrial inkjet equipment
Electric power equipment
Laboratory forensic & pathology equipment
Heavy machinery

Production Dimension

Technical Details

Frequently Asked Questions

Q1: What is rated voltage?

A1: Rated voltage (also known as operating voltage) depends on the connector's insulation material and contact spacing. Some components may not function properly below their rated voltage.

Q2: What is rated current?

A2: Rated current (operating current) is the maximum current the connector can handle continuously. Proper thermal design ensures the connector can withstand this current without damage to insulation or contacts.

Q3: How to choose the suitable connector?

A3: Follow these steps:

Confirm current rating and number of contacts needed
Determine if pre-cable assembly is required
Specify cable gauge
Determine required cable length and material

Tag:

Contact Person: Miss. Gina

Tel: +86 075523019434
